C4-80 POST PORCELAIN ISOLATORS
Video Drawing Parameter table Indicator C4-80 II UHL C4-80 I T C4-80 I UHL C4-80 I T Rated voltage kV 10 10 10 10 Minimum bending strength kN 4 4 4 4 Construction height mm 215 215 190 190 Creepage distance mm 30 30 20 20 Weight kg 2.6 2.6 2.1 2.1 Insulating part diameter D mm 125 125 125 125 Upper flange, D 1 mm 36 36 36 36 Lower flange, D 2 mm 70 70 70 70 Test voltage of (full) lightning impulse kV 80 80 80 80 Марка изолятора: С4-80 II Номинальное напряжение: ... -
Low Voltage N95 Pin type Porcelain Insulator
Video Drawing Parameter table TYPE N95 Standard Applied IEC383-1 Overal Height(H) mm 95 Max. Shed Diameter(D) mm 95 Creepage Distance mm 130 Minimun Breaking Load kN 16 One Minute Wet Withstand Voltage kV 10 Net Weight kg 0.57 -
10kv Shf-10mo Pin Insulator
Rated voltage: 10 kV
Insulator mounting pin diameter: 22mm
Minimum breaking force: 12.5 kN
Weight: 1.7 kg -
-
Проходные изоляторы ИП 10-100 10 кВ
Изолятор ИП-10-100-I 02
Изолятор проходной керамический ИП-10-100-I 02 предназначен для изоляции и проведения токоведущих частей закрытых распределительных устройств, для соединения с открытыми распределительными устройствами или с линиями электропередач на переменное напряжение до 10 кВ, как для работы в атмосфере, так и для закрытых токопроводов.
Структура условного обозначения
И – изолятор
П – проходной
10 – номинальное напряжение, кВ
100 - внутренний диаметр изолятора, мм
I - модификация
0 – климатическое исполнение
2 – категория размещения -
111kn High Voltage Disc Suspension Porcelain Insulator ANSI 52-6
111kn ANSI 52-6 High Voltage Outdoor Disc Suspension Porcelain Insulator
ANSI Class 52-6 Clevis type suspension porcelain insulators
Coupling size Type J
The disc-shaped suspension porcelain insulator is a special insulation control, which can play an important role in overhead transmission line. -
Insulator SHF20 G1 (SHF20 UO)
Specification of SF20UO needle shaped porcelain insulator
Permissible Pollution Level (PP) for PUE with a voltage of 10 kV/20 kV-2/1
Minimum mechanical failure load -13 kN
Leakage path length -325 mm
Withstand voltage 50Hz (dry) -85kV
Withstand voltage 50Hz (in rain) -45kV
Breakdown voltage in insulation medium -160 kV
Weight -3400 grams -
ИЗОЛЯТОР ST-10J（B）
Изолятор штыревой ШФ-10J – это высоковольтный фарфоровый изолятор предназначен для изоляции и крепления проводов на воздушных линиях электропередач напряжением до 10 кВ.
Изолятор ШФ-10J один из самых распространенных штыревых фарфоровых изоляторов.
Изолятор ШФ-10J монтируется на траверсы высоковольтные, оголовья, штыри и крюки КН-22.
Для крепления изолятора ШФ-10J необходимы колпачки К-7, К-9, КП-22.
-
Pin insulator ST-10J（A）
Изолятор штыревой фарфоровый ШФ-10Г -
ANSI C29.5 55-4M Pin Insulator for Bangladesh
The 55-4m pin insulator is an insulator used in power transmission and distribution systems. It is usually made of ceramic or composite materials and has excellent insulation performance and durability.
The design of the 55-4m pin insulator takes into account factors such as ease of installation and maintenance. It is usually installed through pins fixed on the wire pole, which can ensure the stability and safety of the insulator. Meanwhile, its compact structure, light weight, and small surface area help reduce the impact of wind on insulators.
The main function of this type of insulator is to prevent the flow of current to the tower or other grounding facilities, thereby protecting the safety of personnel and equipment. It can isolate power lines and ensure that current is only transmitted through the lines without causing any damage to the surrounding environment.
In summary, the 55-4m pin insulator is a high-performance power insulation device used to provide safe and reliable power transmission and distribution. Its design and material selection make it suitable for various environments, ensuring the normal operation of the power system. -
Straight Head Disc Porcelain Insulator U160B
Cylindrical Head Disc Porcelain Insulator U160B -
Cylindrical Head/ Straight Head Suspension Disc Porcelain Insulator U210BP
Video Drawing Parameter table Fog type suspension porcelain insulators( IEC Class ) ICE Class U210BP Coupling size 20 Dimensions Diameter(D) mm 280 Spacing(H) mm 170 Leakage distance mm 405 Mechanical Values combined M&E strength kn 210 Impact strength nm 10 Routine proof test load kn 105 Electrical Values power frequency dry withstand voltage kv 75 power frequency wet withstand voltage kv 45 Critical impulse flashover voltage,positive kv 125 Criti...
